| Fuselage Dimensions | 1300mmx1300mmx750mm |
| Folding dimension | 500mmx500mmx750mm |
| Wheelbase | 1300mm |
| Material | Aviation aluminum alloy, carbon fiber |
| Body weight | 8KG |
| Maximum takeoff weight | 24kg (near sea level) |
| Maximum load | 10KG |
| Maximum ascent speed | 5m/s |
| Maximum Descent Speed | 5m/s |
| Maximum tolerable wind speed | 12m/s |
| Maximum Flight Altitude | 5000m |
| Maximum flight speed | 20 m/s (no wind environment) |
| Maximum Flight Time | 30-70 minutes |
| Maximum control distance | 10km (open without shelter, no electromagnetic interference) |
| Maximum Flight Climb Altitude | 1000 m |
| Hover accuracy | Vertical: ± 0.5m (when GPS positioning works normally) Horizontal: ± 1m (when GPS positioning works normally) |
| satellite positioning module | GPS/GLONASS/BDS/Galileo |
| Camera | HD 4K 10/30 zoom |
| power system | Integrated FOC power system |
| Working temperature | -20 ℃-50 ℃ |
| Waterproof grade | In the rain, the fuselage can be flushed with water. |
| Battery capacity | 30000mah |
| Operating frequency | 2.4GHz & 5.8GHz Dual Band |
| master control chip | Surging S1 |
| Operating System | Android |
| Signal effective distance | About 10km (open without shelter, no electromagnetic interference) |
| Video output interface | HDMI/Wi-Fi |
| Built-in battery | 7.4V 20000mAh LiPo2S |
| Endurance | 20 hours |
| Display Screen | 7 inch screen, resolution 1920*1200, |
| Maximum brightness | 2000cd/㎡ |
| Memory card type | Maximum support for 128GB capacity microSD card |
| Three-segment switch | Not less than four |
| 2D Rocker | Support |
| Protection level | IP54 |
| Integrated operation page | Flight parameter integration, The image and map can be switched at will |
| Voice broadcast | With adjustable real-time voice broadcast |
